Split-Phase Fan and Blower Motor, 1/4 HP, 48Z Frame, 115V AC Voltage, 1, 725 Nameplate RPM MPN:048S17D2054
Split-Phase Fan and Blower Motor, 1/4 HP, 48Z Frame, 115V AC Voltage, 1, 725 Nameplate RPM
This 1/4 HP Split-Phase Fan and Blower Motor from Leeson is designed for a wide range of applications, including commercial and industrial use. Its 1,725 nameplate RPM provides efficient airflow, while its 48Z frame and 115V AC voltage ensure reliable operation. Suitable for continuous duty cycles, this motor is ideal for applications such as exhaust fans, blowers, and ventilation systems. Its compact design and open drip-proof enclosure make it easy to install and maintain. With a motor service factor of 1.35 and a maximum ambient temperature of 70°C, this motor delivers reliable performance in a variety of environments.
Top product features:
- Split-phase design for improved motor efficiency and reliability
- Continuous duty cycle for uninterrupted operation
- Open drip-proof enclosure design for protection against dust and debris
Top product applications:
- Home HVAC systems
- Industrial ventilation systems
- Commercial air handling units
Fan and Blower Motor, Single Phase, Motor Design Split-Phase, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, 5.0 A Full Load Amps, 48YZ Frame, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Motor Service Factor 1.35, Motor Thermal Protection None, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 70 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.57
- Package Width: 8.61
- Package Height: 8.83
- Package Weight: 14.00
Product info last updated on February 4, 2026 8:32am UTC
Category: Motors
