Vector Motor, 1.5 lb-ft, 1/2 HP, 230/460 V MPN:056H17T15526
Vector Motor, 1.5 lb-ft, 1/2 HP, 230/460 V
The Leeson Vector Motor is a high-performance, 1/2 HP, 3-phase motor designed for demanding applications. With a 1.5 lb-ft torque and 1,725 nameplate RPM, it provides efficient and reliable operation. Suitable for use in a variety of industries, including manufacturing, material handling, and oil and gas, this motor excels in applications requiring high speed and low maintenance. Its compact design and continuous duty cycle make it ideal for use in tight spaces and high-production environments. With a 1,000:1 speed range and 120 Hz operating frequency, this motor delivers exceptional performance and efficiency.
Top product features:
- Three-phase design
- Torque output of 1.5 lb-ft
- Speed range of 1,000:1
Top product applications:
- Pumps and blowers
- Conveyor systems
- Fans and blowers
Vector Motor, Three Phase, Motor Design Three-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 1.6/0.80 A, 56C Frame, Torque 1.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 20.20
- Package Width: 12.90
- Package Height: 13.80
- Package Weight: 29.50
Product info last updated on February 8, 2026 8:05pm UTC
Category: Motors
