Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56C Frame MPN:056C17F5321
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56C Frame
This 1/2 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for a variety of applications. Suitable for use in 115/208-230V AC environments, it can be used in applications such as pumps, fans, and conveyor systems. The motor's capacitor-start design provides a high starting torque, making it ideal for applications that require a boost of power. With a continuous duty cycle and a maximum ambient temperature of 40 degrees C, this motor can handle demanding tasks. Its compact 56C frame and totally enclosed fan cooled design make it a great choice for space-constrained applications.
Top product features:
- Totally Enclosed Fan Cooled design for improved durability and reduced maintenance
- Single Phase motor design with Capacitor-Start for efficient operation and high starting torque
- Continuous Duty Cycle for reliable performance in demanding applications
Top product applications:
- Industrial control systems
- Pumping systems for water treatment plants
- Material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.8/4.4-4.2 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 26.00
Product info last updated on February 1, 2026 12:06pm UTC
Category: Motors
