Three-Phase General Purpose Motor, 3/4 HP, 56C Frame, 208-230/460V AC Voltage, 3, 450 Nameplate RPM MPN:5K37MN37
Three-Phase General Purpose Motor, 3/4 HP, 56C Frame, 208-230/460V AC Voltage, 3, 450 Nameplate RPM
This 3/4 HP, 56C frame three-phase general purpose motor from Leeson is designed for a variety of applications including industrial and commercial use. Its open drip-proof motor enclosure and steel frame provide durability and protection from dust and moisture. The motor's 3,450 RPM and 2.6/1.3 A full load amps make it suitable for continuous duty applications. With a service factor of 1.5 and ball bearings, this motor offers reliable performance and long lifespan. Ideal for use in conveyor systems, pumps, and other industrial equipment, this motor meets CSA and UL standards, ensuring safe and efficient operation.
Top product features:
- Three-Phase General Purpose Motor design provides continuous duty operation
- Ball Motor Bearings ensure smooth and quiet operation
- Motor Thermal Protection is not provided, allowing for operation in a variety of environments
Top product applications:
- Industrial conveyor systems
- Material handling equipment
- Pumps and water treatment systems
General Purpose Motor, Three-Phase, Open Drip Proof Motor Enclosure Design, 3/4 HP, Nameplate RPM 3,450, Frame 56C, Voltage 208-230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 2.6/1.3 A, C-Face Motor Mounting Type, Motor Thermal Protection None, Ins. Class B, Motor Service Factor 1.5, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 74 Percent, Continuous Duty, 3001-3600, CSA Certified, UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 17.00
Product info last updated on January 31, 2026 9:22pm UTC
Category: Motors
