3-Phase Belt Drive Motor, 1/2 HP, 56 Frame, 208-230/460V AC Voltage, 1, 140 Nameplate RPM MPN:5K49MN6081
3-Phase Belt Drive Motor, 1/2 HP, 56 Frame, 208-230/460V AC Voltage, 1, 140 Nameplate RPM
This 3-Phase Belt Drive Motor from Leeson is a reliable and efficient solution for various applications. With a 1/2 HP rating and 1,140 nameplate RPM, it's suitable for use in fans, blowers, and other equipment that require a high level of performance. The motor's totally enclosed fan-cooled design ensures optimal cooling and extends its lifespan. Its compact 56 frame size and cradle base mounting type make it easy to integrate into existing systems. Ideal for use in industrial settings, this motor provides continuous duty operation and is available for immediate shipment.
Top product features:
- Three-Phase Belt Drive Motor design
- Totally Enclosed Fan Cooled motor design
- Continuous Duty Cycle operation
Top product applications:
- Air Handling Units
- Industrial Laundry Equipment
- Commercial Refrigeration Systems
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 1/2 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 2.6-2.6/1.3 A Full Load Amps, 56 Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 27.00
Product info last updated on January 31, 2026 8:48am UTC
Category: Motors
