GeneralPurposeMotor, 3/4hp, 1725RPM, 56C MPN:5KCR49PN0099X
GeneralPurposeMotor, 3/4hp, 1725RPM, 56C
This 3/4 HP general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. With a single phase, capacitor-start/run design and totally enclosed fan cooled (TEFC) enclosure, it provides reliable operation in harsh environments. The motor is rated for 100-120/200-240V AC and has a continuous duty cycle, making it suitable for applications requiring high reliability and efficiency. Its compact size and lightweight design make it easy to install and maintain, while its durable construction ensures long-lasting performance and reduced downtime. Ideal for use in factories, warehouses, and other industrial settings.
Top product features:
- Single Phase
- Totally Enclosed Fan Cooled
- Continuous Duty Cycle
Top product applications:
- Pumps
- Air Compressors
- Fans
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 100-120/200-240V AC, Full Load Amps 8.8/4.4 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 31.00
Product info last updated on February 1, 2026 4:52am UTC
Category: Motors
