GeneralPurposeMotor, 1hp, 1725RPM, 56 MPN:056B17DRR70017A1
GeneralPurposeMotor, 1hp, 1725RPM, 56
This 1hp General Purpose Motor from Leeson is a reliable and efficient solution for a wide range of applications. Suitable for use in 115/208-230V AC environments, it offers a high level of flexibility and versatility. With a nameplate RPM of 1725, this motor provides consistent performance and can handle continuous duty cycles. Its compact 56 frame design makes it easy to integrate into existing systems, while its open drip-proof enclosure ensures reliable operation in various environments. Ideal for use in industrial settings, this motor is perfect for applications such as conveyor systems, pumps, and fans.
Top product features:
- Single Phase operation
- Capacitor-Start/Run motor design
- Continuous duty cycle
Top product applications:
- Pump applications
- Fans and blowers
- Conveyors and material handling equipment
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.0/4.4-4.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.49
- Package Width: 9.69
- Package Height: 11.19
- Package Weight: 38.48
