Pressure Gauge with Diaphragm Seal, 0 to 15 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location MPN:KC301L2515/DSM3511LP
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1835471
Pressure Gauge with Diaphragm Seal, 0 to 15 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location
The Kodiak Pressure Gauge with Diaphragm Seal is a heavy-duty instrument designed for measuring pressure in industrial settings. With a 2 1/2 in dial and 0 to 15 psi range, it's suitable for applications such as boiler monitoring, hydraulic systems, and compressed air lines. The gauge features a 304 stainless steel case and 316 stainless steel socket and tube for durability and resistance to corrosion. Its accuracy of 1.6 percent ensures reliable readings. The gauge is also filled with glycerin for low-temperature operation and features a polished stainless steel ring for easy reading. It's ideal for use in environments with temperatures ranging from -30 to 200 degrees Fahrenheit.
Top product features:
- Measures pressure up to 15 psi
- Has a 2 1/2 in dial for precise reading
- Filled with glycerin for accurate and reliable pressure measurement
Top product applications:
- High-pressure process monitoring in chemical plants
- Industrial pressure measurement in oil refineries
- Pressure monitoring in HVAC systems
Pressure Gauge, Pressure, 2-1/2 In., 30 In. Hg Vac to 0, Connection Size 1/4 In. FNPT, Connection Location Bottom, Smallest Graduation 0.5 In. Hg, Graduations 5 In. hg, Accuracy 1.6 Percent, Case Material 304 Stainless Steel, Case Color Silver, Socket Material 316 Stainless Steel, Tube Material 316 Stainless Steel, Filled With Glycerin, Lens Material Plastic, Ring Material Polished Stainless Steel, Operating Temp. Range -30 Degrees to 200 Degrees F, Characteristics Heavy Duty
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.70
- Package Width: 3.40
- Package Height: 3.50
- Package Weight: 1.75
Product info last updated on February 1, 2026 4:44am UTC
Category: Pressure and Vacuum Measuring
