Locating Pin With Ball-End, Flattened, C=12, Form: D Tool Steel MPN:K0351.122
Locating Pin With Ball-End, Flattened, C=12, Form: D Tool Steel
This flattened ball-end locating pin is a precision tool made from durable D Tool Steel, ensuring reliable performance in demanding applications. Its 12mm diameter head and 8mm shank outside diameter provide a secure fit in metric-based systems, while the 30-degree chamfered shank facilitates easy insertion. Suitable for use in a variety of industries, including automotive, aerospace, and manufacturing, this locating pin is ideal for applications requiring precise alignment and positioning. Its compact size and lightweight design make it easy to handle and store, reducing waste and increasing productivity in high-volume production environments.
Top product features:
- Flattened ball-end design for precise locating and positioning
- Shoulderless design for easy insertion and reduced stress on surrounding components
- 30-degree chamfer angle for smooth insertion and reduced risk of damage to surrounding materials
Top product applications:
- Locating pins are often used in CNC machining for setting the position of a workpiece.
- Locating pins are used in assembly to locate and position parts, ensuring they are properly aligned.
- Locating pins are used in inspection fixtures to locate and position parts for measurement and testing.
Flattened Ball-End Locating Pin, System of Measurement Metric, Shouldered No, Head Shape Flattened Ball End, Head Diameter 12 mm, Head Height 12 mm, Shank Outside Diameter 8 mm, Shank Chamfer Angle 30 Degrees , Material Tool Steel, Shank Length 8 mm, Standards RoHS
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.00
- Package Width: 4.00
- Package Height: 1.00
- Package Weight: 0.02
