Y Strainer, 5" Pipe, Flanged, Cast iron, 200 psi at 150 Degrees F WOG, 125 psi at 450 Degrees F WSP MPN:51FFY-CI125P34-FBI-A7
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1612941
Y Strainer, 5" Pipe, Flanged, Cast iron, 200 psi at 150 Degrees F WOG, 125 psi at 450 Degrees F WSP
This cast iron Y Strainer is designed for use with a variety of fluids, including gas, oil, steam, and water, and is suitable for applications in high-temperature environments up to 450°F. The 304 stainless steel screen provides effective filtration and can withstand pressures up to 200 psi. With a flow capacity of 364 gpm, this strainer is ideal for use in industrial settings where high-pressure and high-temperature conditions are present. Its compact design and flanged connection make it easy to install and integrate into existing piping systems, reducing downtime and increasing efficiency.
Top product features:
- Cast iron housing provides durability and resistance to corrosion
- 304 Stainless Steel screen material offers high resistance to corrosion and chemical damage
- Perforated screen size of 0.125 in allows for effective filtration and flow regulation
Top product applications:
- Gas piping systems
- Oil well drilling operations
- Steam distribution systems
Y Strainer, Pipe Size 5 in, Maximum Pressure at 100 deg F 200 psi, Length 15 5/8 in, Height 15 5/8 in, Blow Off Port 2 in, Screen Material 304 Stainless Steel, Perforated Screen Size 0.125 in, Mesh Size Not Applicable, Housing Material Cast Iron, Class 125, Cv Flow Factor 364 gpm, For Use With Gas, Oil, Steam, Water, Includes Screen Screen Included, Maximum Pressure 200 psi, Maximum Temperature 450 Degrees F, Micron Rating 3,175 micron, Port 1 Connection Size 5 in, Port 1 Connection Type Flanged
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.00
- Package Width: 22.00
- Package Height: 12.00
- Package Weight: 105.00
Product info last updated on January 22, 2026 3:40am UTC
Category: Filtration
