2" Carbon Steel Wafer Check Valve MPN:DD2R-CS-361IX-200
2" Carbon Steel Wafer Check Valve
The 2in Carbon Steel Wafer Check Valve from Keckley is a reliable and efficient solution for various industrial applications. Designed for inline use, this valve features a single flow design and can be mounted in both horizontal and vertical orientations. With a maximum water pressure of 285 psi at 100°F, it is suitable for a range of fluid handling systems. The valve's carbon steel body and 316 stainless steel spring ensure durability and resistance to corrosion. Ideal for use in water treatment, chemical processing, and other industries, this check valve provides a cost-effective and low-maintenance solution for controlling fluid flow.
Top product features:
- Flow design is single
- Body design is inline wafer
- Seal material is Buna-N
Top product applications:
- Industrial Process Control: This check valve is used in industrial process control systems to prevent backflow and ensure a safe flow of fluids in various applications.
- Water Treatment Plants: The valve is used in water treatment plants to prevent contamination and backflow of treated water into the raw water supply.
- Chemical Processing: The check valve is used in chemical processing to prevent backflow and ensure a safe flow of chemicals in various applications, such as in pipelines and storage tanks.
Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Wafer, Body Material - Valves Carbon Steel, Pipe or Tube Size 2 in, Connection Type Flanged Wafer x Flanged Wafer, Cracking Pressure 1.046 psi, Mounting Orientation Horizontal, Vertical, Seal Material Buna-N, Max. Temp. - Valves 100 Degrees F, Max. Water Pressure - Valves 285 psi @ 100 Degrees F, Max. Steam Pressure - Valves Not Rated, Seat Material Buna-N, Spring Material 316 Stainless Steel
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.90
- Package Width: 4.70
- Package Height: 2.70
- Package Weight: 5.10
Product info last updated on January 19, 2026 9:52pm UTC
Category: Pipes, Valves and Fittings
