Pivot Hinge, Stainless Steel, Full Mortise Mounting, 1 5/16 in Leaf W x 7 1/4 in Leaf H MPN:7230F INT RH US32D
Pivot Hinge, Stainless Steel, Full Mortise Mounting, 1 5/16 in Leaf W x 7 1/4 in Leaf H
The IVES Pivot Hinge is a heavy-duty, stainless steel hinge designed for commercial and industrial applications. Its 1,000 lb load capacity and 180-degree range of motion make it ideal for high-traffic doors, such as those found in healthcare facilities, offices, and restaurants. The hinge's lubricated sleeve bearing type and stainless steel finish ensure smooth operation and durability. Its full mortise mounting design provides a secure fit, while the included hardware and steel pin material add to its overall strength. Suitable for doors with a thickness of 1 3/4 in, this hinge is a reliable solution for demanding environments.
Top product features:
- Lubricated Sleeve Bearing Type
- 1,000 lb Load Capacity
- 180 Degrees Range of Motion
Top product applications:
- Kitchen Cabinets
- Office Furniture
- Medical Equipment Rooms
Pivot Hinge, Stainless Steel Material, Stainless Steel Finish, 1,000 lb Load Capacity, With Holes, 6 Holes per Leaf, No Ligature Resistant, 180 Degrees Range of Motion, Orientation Right Hand, 0.375 in Door Leaf Thickness, 0.375 in Frame Leaf Thickness, 1 3/4 in Required Door Thickness, Lubricated Sleeve Bearing Type, Square Corners, Included Hardware, Full Mortise Mounting, 1/2 in Pin Dia., Steel Pin Material, Nonremovable Pin Type, ANSI A156.4 Standards, Door Leaf Height 7 1/4 in
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.50
- Package Width: 2.75
- Package Height: 3.00
- Package Weight: 2.20
Product info last updated on February 15, 2026 1:23pm UTC
Category: Door Hardware and Components
