Thread Ring Gage, Thread Size M10.0-1.50 MPN:4120-10N
Thread Ring Gage, Thread Size M10.0-1.50
Ensure precise thread measurement with the Thread Ring Gage from Insize. This metric thread ring gauge is designed for use in a variety of applications, including quality control and inspection of threaded components. Its adjustable design and long form calibration certificate provide accuracy and reliability. With a pitch diameter of 10mm and a thread length of 8mm, this gauge is ideal for measuring threads in metric sizes. Perfect for industries such as aerospace, automotive, and manufacturing, this gauge helps ensure that threaded components meet specifications, reducing the risk of failure and ensuring smooth operation.
Top product features:
- Thread Ring Gage is adjustable
- Thread Ring Gage measures pitch diameter of 10mm
- Thread Ring Gage has a no-go member for 1.5mm pitch diameter
Top product applications:
- Thread ring gage for quality control in a manufacturing facility to ensure thread consistency and accuracy.
- Thread ring gage for use in a machine shop to verify the thread size and pitch of metric threads on machinery and equipment.
- Thread ring gage for inspection and testing of threaded components in a laboratory or R&D setting to ensure compliance with ISO 1502 standards.
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Tool Steel, Dimension Type Metric, Gauge Type No-Go (Minus), Pitch Diameter 10mm, Pitch Diameter - No-Go Member 1.5 mm, Thread Class 6G, Thread Length 8mm, Thread Size M10 x 1.50, Thread Type Metric, Finish Uncoated, Gauge Design Adjustable, Included Certification Certificate of Inspection, Standards ISO 1502, Tolerance Class 6G
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.65
- Package Width: 1.61
- Package Height: 0.63
- Package Weight: 0.11
Product info last updated on February 5, 2026 12:34pm UTC
Category: Measuring and Marking Tools
