Thread Ring Gage, Thread Size M24.0-3.00 MPN:4120-24N
Thread Ring Gage, Thread Size M24.0-3.00
Ensure precise thread measurements with the Thread Ring Gage from Insize. This metric tool is designed for use with M24.0-3.00 threads, featuring a pitch diameter of 24mm and a no-go member of 3mm. Constructed from durable tool steel, this gauge is adjustable and ideal for applications requiring high accuracy, such as quality control and inspection. The long form calibration certificate provides assurance of the gauge's precision. Suitable for use in a range of industries, including aerospace, automotive, and manufacturing, this thread ring gage helps maintain quality standards and ensures compliance with ISO 1502 standards.
Top product features:
- This product is a No-Go (Minus) gauge, meaning it checks the thread size to ensure it is smaller than the specified size.
- The gauge is made of tool steel, providing durability and resistance to wear.
- The gauge is adjustable, allowing for precise measurement and calibration.
Top product applications:
- Quality Control
- Inspection of threaded components
- Precision manufacturing
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Tool Steel, Dimension Type Metric, Gauge Type No-Go (Minus), Pitch Diameter 24mm, Pitch Diameter - No-Go Member 3 mm, Thread Class 6G, Thread Length 14mm, Thread Size M24 x 3.00, Thread Type Metric, Finish Uncoated, Gauge Design Adjustable, Included Certification Certificate of Inspection, Standards ISO 1502, Tolerance Class 6G
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.95
- Package Width: 2.95
- Package Height: 1.18
- Package Weight: 0.49
Product info last updated on February 9, 2026 12:03pm UTC
Category: Measuring and Marking Tools
