Thread Ring Gage, Thread Size M22.0-2.50 MPN:4120-22N
Thread Ring Gage, Thread Size M22.0-2.50
Accurately measure and verify threads with the Insize Thread Ring Gage, designed for precision and reliability. This long-form calibration certificate ensures precise measurements, meeting ISO 1502 standards. The adjustable gauge is ideal for inspecting threads in various applications, including manufacturing, quality control, and maintenance. Its durable tool steel construction and uncoated finish withstand repeated use. The gauge is perfect for measuring thread sizes M22.0-2.50, with a pitch diameter of 22mm and a no-go member of 2.5mm, making it a valuable tool for industries requiring precise thread inspection, such as aerospace, automotive, and oil and gas.
Top product features:
- Thread Ring Gage provides a No-Go (Minus) measurement to ensure thread diameter is within specifications.
- Thread Ring Gage has an Adjustable Gauge Design to accommodate various thread sizes.
- Thread Ring Gage is calibrated to the ISO 1502 standard for thread measurement accuracy.
Top product applications:
- Thread inspection for quality control
- Checking thread alignment and pitch in manufacturing
- Measuring thread accuracy in production settings
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Tool Steel, Dimension Type Metric, Gauge Type No-Go (Minus), Pitch Diameter 22mm, Pitch Diameter - No-Go Member 2.5 mm, Thread Class 6G, Thread Length 14mm, Thread Size M22 x 2.50, Thread Type Metric, Finish Uncoated, Gauge Design Adjustable, Included Certification Certificate of Inspection, Standards ISO 1502, Tolerance Class 6G
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.07
- Package Width: 2.87
- Package Height: 1.10
- Package Weight: 0.57
Product info last updated on February 5, 2026 2:06am UTC
Category: Measuring and Marking Tools
