Threaded Ring Gauge Dimension Type Inch MPN:4121-81N
Threaded Ring Gauge Dimension Type Inch
Ensure precise threaded component measurements with the Threaded Ring Gauge from Insize. This long form calibration gauge is designed for use with #8-32 UNC threads, featuring a pitch diameter of 0.164 inches and a thread class of 2A. The gauge is constructed from steel and is available in a no-go (minus) configuration, making it ideal for inspecting threaded components to ensure they meet specifications. Suitable for a range of industries, including aerospace, automotive, and manufacturing, this gauge provides accurate measurements and helps prevent costly errors, improving overall quality control and production efficiency.
Top product features:
- Threaded design for precise UNC thread measurement
- No-go (minus) gauge for checking thread size
- Solid gauge design for durability and accuracy
Top product applications:
- Threaded Ring Gauge can be used to inspect the thread size and pitch of #8-32 UNC threads in various applications such as
- Quality control in manufacturing
- Thread inspection in aerospace and defense industries
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Steel, Dimension Type Inch, Gauge Type No-Go (Minus), Pitch Diameter 0.164 in, Thread Class 2A, Thread Length 5mm, Thread Size #8-32, Thread Type UNC, Finish Uncoated, Gauge Design Solid, Included Certification Certificate of Inspection, Standards ANSI B1.2, Tolerance Class 2A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.20
- Package Width: 2.09
- Package Height: 0.91
- Package Weight: 0.04
Product info last updated on February 15, 2026 2:25pm UTC
Category: Measuring and Marking Tools
