Threaded Ring Gauge Dimension Type Inch MPN:4121-3B2N
Threaded Ring Gauge Dimension Type Inch
Accurately measure threaded components with Insize's Threaded Ring Gauge. This long-form calibration gauge ensures precise measurements for 3/4 in.-16 UNF threads. The no-go gauge prevents over-tightening and damage to threads. Made from steel, it features a solid design and uncoated finish. Suitable for quality control and inspection in industries such as aerospace, automotive, and manufacturing. The gauge's compact size and lightweight design make it easy to use in tight spaces. A certificate of inspection is included with each purchase, ensuring compliance with ANSI B1.2 standards. Perfect for ensuring thread accuracy and preventing costly mistakes.
Top product features:
- Threaded design allows for precise measurement of 3/4 In.-16 UNF threads
- Solid gauge design ensures durability and resistance to wear
- No-Go (Minus) gauge type provides a precise measurement of thread size, ensuring accurate inspection and quality control
Top product applications:
- Quality Control in Manufacturing
- Threaded Ring Gauge is used to inspect the thread on parts and ensure they meet the required specifications.
- Thread Inspection in Aerospace Industry
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Steel, Dimension Type Inch, Gauge Type No-Go (Minus), Pitch Diameter 3/4 in, Thread Class 2A, Thread Length 10mm, Thread Size 3/4 In.-16, Thread Type UNF, Finish Uncoated, Gauge Design Solid, Included Certification Certificate of Inspection, Standards ANSI B1.2, Tolerance Class 2A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.17
- Package Width: 2.17
- Package Height: 0.91
- Package Weight: 0.21
Product info last updated on March 17, 2026 6:40pm UTC
Category: Measuring and Marking Tools
