Threaded Ring Gauge Dimension Type Inch MPN:4121-5D2
Threaded Ring Gauge Dimension Type Inch
Accurately measure threaded components with the Threaded Ring Gauge from Insize. This steel gauge is calibrated for inch dimensions and features a go (plus) tolerance class 2A. With a pitch diameter of 5/16 in and thread size of 5/16 In.-24, it's ideal for verifying thread quality in manufacturing and quality control. Its solid design and uncoated finish ensure reliable performance. The gauge is certified to ANSI B1.2 standards and includes a certificate of inspection. Suitable for use in a variety of industries, including aerospace, automotive, and construction, this gauge helps ensure compliance with industry specifications and standards.
Top product features:
- Calibration Certificate included for verification of accuracy
- Long Form Calibration Certificate provides detailed information for inspection and quality control
- Threaded Ring Gauge is designed to fit UNF thread type for precise measurement and inspection
Top product applications:
- Quality Control Inspection
- Threaded fastener inspection in manufacturing and production environments
- Machining and metalworking operations
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Steel, Dimension Type Inch, Gauge Type Go (Plus), Pitch Diameter 5/16 in, Thread Class 2A, Thread Length 8mm, Thread Size 5/16 In.-24, Thread Type UNF, Finish Uncoated, Gauge Design Solid, Included Certification Certificate of Inspection, Standards ANSI B1.2, Tolerance Class 2A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.17
- Package Width: 2.08
- Package Height: 0.91
- Package Weight: 0.13
Product info last updated on March 5, 2026 1:26am UTC
Category: Measuring and Marking Tools
