Threaded Ring Gauge Dimension Type Inch MPN:4121-5D1N
Threaded Ring Gauge Dimension Type Inch
Accurately verify the thread pitch and diameter of 5/16-18 UNC threads with Insize's Threaded Ring Gauge. This no-go gauge ensures that threads meet the required specifications, preventing costly mistakes and ensuring smooth assembly. Ideal for quality control and inspection in industries such as aerospace, automotive, and manufacturing, this gauge provides a reliable and precise measurement. Its long form calibration certificate and ANSI B1.2 standard compliance guarantee accuracy and consistency. With a lead time of just 3 days and a minimum order quantity of 1, this gauge is perfect for one-off projects or large-scale production runs.
Top product features:
- Provides a no-go measurement for threads to ensure proper fit and prevent damage
- Features a solid gauge design for accuracy and durability
- Includes a calibration certificate for precise calibration and quality assurance
Top product applications:
- Quality Control in Manufacturing
- Inspecting threaded parts to ensure they meet specifications
- Measuring and verifying thread dimensions on equipment and machinery
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Steel, Dimension Type Inch, Gauge Type No-Go (Minus), Pitch Diameter 5/16 in, Thread Class 2A, Thread Length 8mm, Thread Size 5/16 In.-18, Thread Type UNC, Finish Uncoated, Gauge Design Solid, Included Certification Certificate of Inspection, Standards ANSI B1.2, Tolerance Class 2A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.24
- Package Width: 2.09
- Package Height: 0.91
- Package Weight: 0.13
Product info last updated on March 26, 2026 1:15am UTC
Category: Measuring and Marking Tools
