Threaded Ring Gauge Dimension Type Inch MPN:4121-102N

Ensure precise thread measurements with the Insize Threaded Ring Gauge, designed for #10-32 UNF threads. This long-form gauge is ideal for inspecting thread pitches, measuring thread length, and verifying thread class compliance. Its solid design and uncoated finish ensure accurate readings. The gauge is calibrated to ANSI B1.2 standards and comes with a certificate of inspection. Use it for quality control in manufacturing, maintenance, and repair applications. Benefit from its ease of use and reliability in verifying thread integrity, reducing errors, and ensuring compliance with industry standards. Its compact size makes it perfect for storage and transport.

Top product features:

• Threaded design allows for precise measurement of threaded holes
• No-Go (Minus) gauge design ensures that measured holes are undersized
• Solid gauge design provides a durable and stable measurement tool

Top product applications:

• Threaded Ring Gauge can be used to inspect the thread pitch diameter of a #10-32 UNF thread to ensure it meets the 2A tolerance class.
• Threaded Ring Gauge can be used as a no-go gauge to check the minimum thread size of a #10-32 UNF thread to ensure it does not fall below the 2A tolerance class.
• Threaded Ring Gauge can be used to verify the thread length of a #10-32 UNF thread to ensure it meets the specified length of 5mm.
