Threaded Ring Gauge Dimension Type Inch MPN:4121-102
Threaded Ring Gauge Dimension Type Inch
Accurately inspect threaded components with the Threaded Ring Gauge from Insize. This long-form calibration certificate ensures precision measurement for thread sizes #10-32. Made from durable steel, the gauge is designed for repeated use and features a solid construction. With a tolerance class of 2A, it meets ANSI B1.2 standards. Ideal for quality control and manufacturing applications, this gauge is suitable for industries such as aerospace, automotive, and general manufacturing. Its compact size and lightweight design make it easy to use and store. Perfect for inspecting threads on parts, assemblies, and finished products.
Top product features:
- Threaded design for precise measurement of threads
- Calibration certificate included for assurance of accuracy
- Solid gauge design for durability and long-term use
Top product applications:
- Threaded Ring Gauge can be used as a go gauge to verify the minimum thread size on a part.
- Threaded Ring Gauge can be used as a go gauge to verify the minimum thread size on a thread cutting die.
- Threaded Ring Gauge can be used as a go gauge to verify the minimum thread size on a thread inspection fixture.
Threaded Ring Gauge, Long Form Calibration Certificate No, Material Steel, Dimension Type Inch, Gauge Type Go (Plus), Pitch Diameter 0.19 in, Thread Class 2A, Thread Length 6mm, Thread Size #10-32, Thread Type UNF, Finish Uncoated, Gauge Design Solid, Included Certification Certificate of Inspection, Standards ANSI B1.2, Tolerance Class 2A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.20
- Package Width: 2.09
- Package Height: 0.91
- Package Weight: 0.05
Product info last updated on February 10, 2026 6:32am UTC
Category: Measuring and Marking Tools
