Cylindrical, Inductive Proximity Sensor, 8 mm Dia., Brass, M12, 3 Wires, Unshielded MPN:IE5288
Cylindrical, Inductive Proximity Sensor, 8 mm Dia., Brass, M12, 3 Wires, Unshielded
This inductive proximity sensor is a compact, cylindrical device ideal for detecting the presence or absence of metal objects in various applications. With a small 8mm diameter and maximum detecting distance of 4mm, it is perfect for use in tight spaces or for detecting small metal parts. The sensor operates at a frequency of 300Hz and can be powered by a wide range of DC voltages (10-36V). Its IP67 rating and operating temperature range of -13°F to 158°F make it suitable for use in harsh industrial environments. It's ideal for use in manufacturing, material handling, and automation applications.
Top product features:
- Cylindrical shape allows for easy mounting in tight spaces
- Detects objects at a distance of up to 4 mm
- Operates at a frequency of 300 Hz for reliable detection
Top product applications:
- Position sensing in industrial automation applications
- Monitoring material levels in storage silos
- Detecting metal objects in conveyor systems
Inductive Cylindrical Proximity Sensor, Inductive, 8 mm, Proximity Sensor Power Requirement 10 to 36V DC, Unshielded, Proximity Sensor Operating Frequency 300 Hz, Proximity Sensor Output Circuit Type 3 Wire PNP, Max. Detecting Distance 4 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NO, IP Rating IP67, Case Material Brass White Bronze Coated, Length 62 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: DE
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 3.80
- Package Height: 0.60
- Package Weight: 0.05
Product info last updated on February 11, 2026 8:33pm UTC
Category: Industrial Electrical Controls and Automation
