Encoder, Output A, B, Z, Hollow, 60mm dia. MPN:ROP520
Encoder, Output A, B, Z, Hollow, 60mm dia.
This high-performance encoder is ideal for applications requiring precise speed and position measurement. With a resolution of 10,000 nsec, it provides accurate and reliable data for a range of industries, including robotics, CNC machining, and medical devices. The encoder's hollow shaft design and 12mm diameter allow for easy integration into existing systems, while its compact size and low power consumption make it suitable for space-constrained applications. Its high speed capability of 12,000 RPM also makes it suitable for high-speed applications such as motors, gearboxes, and other mechanical systems.
Top product features:
- Hollow shaft design for easy integration with existing equipment
- Output available in HTL and TTL formats for compatibility with various control systems
- Resolution of 10,000 nsec for precise position measurement and control
Top product applications:
- Motor Speed Measurement
- Motor Position Feedback
- Robotics and Automation
Encoder, Parallel, Output Type HTL, TTL, Power Supply 4.75 to 30 VDC Adapter, Shaft Type Hollow, Shaft Diameter 12 mm, Starting Torque 150 gf-cm, Rotor Inertia 80 g/sq cm, Maximum Speed 12,000 RPM, Cable Length 328 2/25 ft, Cable Connection M12 8 Pin Plug, Rear, Side Cable Entry Location, Overall Diameter 2 5/16 in, Overall Width 64.4 mm, Overall Depth 67 mm, Standards CE, Encoder Style Hollow Shaft, Encoder Type Incremental, Overall Length 83 mm, Resolution 10,000 nsec, Voltage 4.75-30V DC
Additional Information
- Country of Origin: PL
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.90
- Package Width: 5.60
- Package Height: 4.10
- Package Weight: 1.05
