Lever Wire Connector, 10 AWG Max, 3 Port, Blue, Polycarbonate Insulation, 1, 000 V, 30 A, 225 PK MPN:30-25L33J
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G416123963
Lever Wire Connector, 10 AWG Max, 3 Port, Blue, Polycarbonate Insulation, 1, 000 V, 30 A, 225 PK
The Ideal Lever Wire Connector is a reliable and versatile solution for electrical connections. Suitable for use with copper and copper-clad aluminum conductors, this 3-port connector features polycarbonate insulation and a maximum operating temperature of 221°F. With a maximum voltage of 1,000 V and current rating of 30 A, it's ideal for a variety of applications, including industrial control panels, power distribution systems, and electrical enclosures. The connector's compact size and lever-operated design make it easy to use and install, while its CE, cUL, and UL certifications ensure compliance with industry standards.
Top product features:
- 3 Port design allows for multiple connections to be made at once.
- Polycarbonate insulation provides electrical isolation and protects against electrical shock.
- Stranded wire compatibility up to 10 AWG enables use with a wide range of wire sizes.
Top product applications:
- Automotive wiring harnesses
- Electrical panel assemblies
- Commercial electrical wiring installations
Lever Wire Connector, Color Blue, For Conductor Material Copper, Copper-Clad Aluminum, For Minimum Wire Size - Stranded 22 AWG, For Maximum Wire Size - Stranded 10 AWG, Housing Material Polycarbonate, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 600 V, Overall Height 0.43 in, Overall Length 0.89 in, Overall Width 0.94 in, Connector Type Lever, UL 94 Flammability Rating V-2, Number of Ports 3, RoHS Compliant Yes, Standards CE, cUL, UKCA, UL
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 3.75
- Package Width: 5.75
- Package Height: 9.25
- Package Weight: 3.00
Product info last updated on February 23, 2026 7:46am UTC
Category: Electrical Connectors
