Hylomar Advanced Formulation Gasket & Jointing Compound, 250 mL, Blue MPN:HUBA02

• Hylomar Advanced Formulation is a solvent-free, non-setting, non-hardening gasket and jointing compound, supplied in a 250 mL cartridge. Designed as a gasket dressing and flange sealant, it is a mobile compound that fills and seals surface imperfections in flange mating surfaces rather than leaving a set film between them. It does not set or harden, so parts can be assembled immediately or left indefinitely before making the joint, and dismantled components can be cleaned by rubbing with an acetone-soaked cloth without scraping. It resists most automotive fluids and many other chemicals, along with joint vibration, shock, and differential thermal expansion, and operates from -55°C to 250°C (-67°F to 482°F). Manufacturer Specifications: Product: Hylomar Advanced Formulation · Type: Solvent-free, non-setting, non-hardening gasket & jointing compound Color: Blue · Appearance: Non-setting paste Specific gravity: 1.16–1.20 (ASTM D4659) Viscosity: 250,000 ±50,000 mPa·s (Spindle No. 6 @ 2.5 rpm, 25°C
• BS 5350 Part B9) Temperature range: -55°C to 250°C (-67°F to 482°F) Flash point: 195°C (383°F) (ASTM D92) · Auto-ignition: 429°C (804.2°F) (ASTM E659) Solubility in water: None · Typical surface finish: 2.0 μm Ra · Coverage: 2.0 m² per 100 g Non-hardening / non-setting: Yes · Assembly time: Immediate or indefinite · Cleanup: Acetone (no scraping) Hazard classification: Non-hazardous (per manufacturer
• see SDS) Shelf life: Minimum 3 years, unopened, stored 5°C to 25°C (41°F to 77°F) Typical applications (per manufacturer): gasket dressing and flange sealing against lubricants and automotive fluids
• cylinder liners to engine block, cylinder head cam caps, electric motor end plate covers, fuel injector gland nuts.
