Paralleling Tee, Blue, Taper Nose, Ser 15 MPN:HBL15PTBL
Free Shipping
In Stock
The HUBBELL Paralleling Tee, Series 15, is a versatile and reliable device designed for temporary electrical power distribution applications. Its plug-in design and taper nose configuration make it easy to use in a variety of settings, from construction sites to emergency response situations. With a high amperage rating of up to 150 A and a voltage rating of 600V AC or 250V DC, this paralleling tee ensures safe and efficient power distribution. Ideal for use in harsh environments, it meets NEMA Type 12, 3R, and 4X requirements, and is UL Listed and cUL Listed for added assurance.
Top product features:
- Amperage/Current Rating: Rated for up to 150 A (AC/DC) for high-capacity power distribution.
- Suitable for use at 600V AC or 250V DC for flexibility in various electrical applications.
- Female-Male-Male configuration with insulated thermoplastic elastomer housing and brass contacts for reliable connectivity.
Top product applications:
- Temporary electrical power distribution applications
- Emergency backup power systems
- Construction site electrical power distribution
The HUBBELL Paralleling Tee, Series 15, is a single pole device intended for temporary electrical power distribution applications. This plug-in paralleling tee features a taper nose and is compatible with Series 15 connectors. It has a female-male-male configuration and is constructed with an insulated thermoplastic elastomer housing and brass contacts for reliable connectivity in demanding settings.
Key Features of the HUBBELL Paralleling Tee, Series 15:
- Amperage/Current Rating: Rated for up to 150 A (AC/DC)
- Voltage Rating: Suitable for use at 600V AC or 250V DC
- Configuration: Female-Male-Male gender
- single conductor
- one-pole design
- Material: Housing made from thermoplastic elastomer
- contact material is brass
- Mounting Style: Cord mounted paralleling tee
- NEMA Enclosure Ratings: Meets NEMA Types 12, 3R, and 4X requirements
- Temperature Range: Operates continuously from -40°C to +75°C (without impact)
- -25°C minimum with impact
- Standards Compliance: UL Listed, cUL Listed
- meets National Electric Code (NEC), ANSI/NFPA 70 standards
- fits UL1691 requirements
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.00
