Locking Receptacle, L15-30R, 30 A, 250V AC, Single Phase, 3 Pole, Flush Mount, Black MPN:HBL2720ST
Free Shipping
In Stock
The HUBBELL Locking Receptacle is a reliable and efficient solution for commercial and industrial settings, providing a secure and easy-to-use connection for 30A, 250V AC single-phase applications. Featuring spring clamp terminals and high-impact nylon housing, this receptacle allows for fast termination and durable performance in a wide range of environments. Suitable for use in heavy-duty applications such as construction sites, manufacturing facilities, and data centers, this locking receptacle ensures a secure and reliable connection, reducing downtime and increasing productivity. Its compact design and flush mount feature make it an ideal choice for tight spaces and easy installation.
Top product features:
- Spring clamp terminals allow for faster termination without the need for screwdrivers or torque wrenches.
- High-impact nylon housing provides durability.
- Face color coding by voltage aids in identifying and mating with compatible devices.
Top product applications:
- Commercial and industrial settings
- High-impact applications such as construction sites or factories
- Outdoor environments with extreme temperatures
The HUBBELL Locking Receptacle is a 30A, 250V AC twist-lock receptacle intended for use in commercial and industrial settings. Featuring spring clamp terminals that do not require screwdrivers or torque wrenches, this device allows for faster termination without the need for additional tools. High-impact nylon housing provides durability, while face color coded by voltage aids in identifying and mating with compatible devices.
Key Features of the HUBBELL Locking Receptacle:
- Amperage/Voltage Rating: Rated for 30 amps at 250V AC single phase
- NEMA Configuration: L15-30R locking configuration with polarization
- Wire Connection Type: Spring clamp terminals support solid (14–10 AWG) and stranded (14–8 AWG) wires, including compact stranded types
- Contact Material: Brass contacts
- Housing Material: Impact-resistant nylon construction
- UL 94 V-2 flammability rating
- Operating temperature range: -40°F to 167°F environments
- Mount Type & Hardware: Flush mount design
- includes mounting strap and hardware
- Circuit Details: Grounded, three poles, four wires configuration
- NEMA Enclosure/IP Rating: NEMA type 1 enclosure
- IP20 rated protection against solid objects over 12mm
- Standards Compliance: Meets CSA C22.2 and UL 498 standards for performance requirements
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.10
- Package Width: 2.50
- Package Height: 2.40
- Package Weight: 0.23
