Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded MPN:AFR15TRBK
Free Shipping
In Stock
The HUBBELL 15A, 125V AC Flush Mount Duplex Receptacle is a commercial-grade electrical outlet designed for standard power distribution applications. This tamper-resistant receptacle features integrated arc fault circuit interrupter (AFCI) technology, providing enhanced safety and protection against electrical shock. Suitable for use in a variety of settings, including offices, schools, and healthcare facilities, this receptacle mounts flush to the wall, reducing visual clutter and improving aesthetics. Its durable construction and compliance with rigorous safety standards make it an ideal choice for applications where reliability and safety are paramount.
Top product features:
- AFCI technology interrupts the circuit when an arc is detected.
- Tamper resistant internal shutters block insertion of most foreign objects into the slots.
- Supports both back and side wire connections using screw terminals that accommodate three wires (2-pole).
Top product applications:
- Commercial office spaces
- Residential homes
- Industrial facilities
The HUBBELL 15A, 125V AC Flush Mount Duplex Receptacle is a commercial-grade electrical outlet suitable for use in standard power distribution applications. This duplex receptacle includes arc fault circuit interrupter (AFCI) technology that interrupts the circuit when an arc is detected. The unit is tamper resistant
- mounts flush to the wall.
Key Features of the HUBBELL 15A, 125V AC Flush Mount Duplex Receptacle:
- AFCI: Integrated Arc Fault Circuit Interrupter interrupts current flow if certain types of arcing conditions are detected.
- Amperage/Voltage: Rated for 15 amps and 125V AC operation.
- NEMA Configuration: Standard duplex outlet with NEMA 5-15R configuration.
- Mounting Type: Flush mount design suitable for single-gang installations.
- Tamper Resistant: Includes internal shutters designed to block insertion of most foreign objects into the slots.
- Wiring Method: Supports both back and side wire connections using screw terminals
- accommodates three wires (2-pole).
- Material: Constructed from nylon housing material rated for temperatures between -30°F to 150°F.
- Standards Compliance: Certified to CSA C22.2 No.42, UL498, UL Federal Specification WC-596, NEMA WD-6, and UL1699A E366570 standards.
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.25
- Package Width: 2.00
- Package Height: 5.00
- Package Weight: 0.25
