Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded MPN:HBL8200SGA

• The HUBBELL 15A Duplex Receptacle 125VAC 5-15R BN is a duplex receptacle rated for 15A and 125VAC. It features tamper-resistant construction and is rated for use at 15 amps and 125 volts AC. The unit includes integral wire leads for fast installation, nickel-plated brass contacts, and a four-point grounding system to provide redundant ground continuity.





  Key Features of the HUBBELL 15A Duplex Receptacle:





  • Amperage/Voltage: Rated for 15 A, 125 VAC operation


  • NEMA Configuration: NEMA 5-15R duplex outlet


  • Contact Material: Nickel-plated brass contacts


  • Tamper Resistant: Tamper-resistant mechanism


  • Grounding System: Four-point grounding system


  • Wire Connection Type: Integral wire leads with screw terminals support back or side wiring methods


  • Mounting Type: Flush mount with included mounting hardware
  • standard size device suitable for single gang installations


  • Housing Material & Flammability Rating: Thermoplastic housing meets UL94V-0 and UL94-5VA flammability standards


  • Operating Temperature Range: -40°C minimum (without impact) to +75°C maximum continuous use
  • withstands up to 167°F (75°C)


  • Certifications & Standards: CSA Certified C22.2 No.42 File 285, Federal Specification W-C-596, NEMA WD-6, UL498 File E2186 compliant
