Watertight Pin & Sleeve Receptacle, 60 A, 600V AC, Three Phase, 3 Pole, IEC Grounding, Black MPN:HBL460R5W
Free Shipping
In Stock
The HUBBELL IEC Pin and Sleeve Receptacle is designed for high-capacity power connections in industrial settings, rated for 60A and 600V AC. Its impact-resistant Zytel 101 nylon housing and flange materials provide durability in demanding environments. This receptacle supports three-phase power with four wires and three poles, includes grounding per IEC standards, and features a flanged design with a spring-loaded cap to limit moisture ingress. Suitable for use in applications such as manufacturing facilities, construction sites, and outdoor areas, this receptacle offers reliable and efficient power connections, making it an ideal solution for industries with high-power requirements.
Top product features:
- Watertight design helps to limit moisture ingress
- Impact-resistant Zytel 101 nylon housing provides durability in demanding environments
- Grounding per IEC standards ensures safe electrical connections
Top product applications:
- Industrial Settings
- Heavy-Duty Machinery
- High-Capacity Power Connections
The HUBBELL IEC Pin and Sleeve Receptacle is a watertight electrical device intended for use in industrial settings where high-capacity power connections are specified. Rated for 60A and 600V AC, this receptacle features a straight connection orientation with screw terminal wire connections. It is constructed from impact-resistant Zytel 101 nylon housing and flange materials, providing durability in demanding environments. The unit supports three-phase power with four wires and three poles, includes grounding per IEC standards, and has a flanged design with a spring-loaded cap designed to help limit moisture ingress.
Key Features of the HUBBELL IEC Pin & Sleeve Receptacle:
- Current/Voltage Rating: 60A, 600V AC
- rated for use at high-power requirements
- Body/Flange Material: Zytel 101 Nylon (impact-resistant)
- Cord Size Compatibility: Accepts wire sizes from 8 AWG to 2 AWG
- Operating Temperature Range: -40°C to 75°C
- see specifications for recommended usage conditions
- NEMA Enclosure/IP Rating: NEMA 4X and IP67 (see standards for details)
- Number of Poles/Wires: Three poles, four wires
- grounded configuration
- Horsepower Rating: Up to 25 hp (15 hp listed as well)
- Screw Material: Constructed with corrosion-resistant stainless steel screws
- Resistance Properties: Impact-resistant, moisture-resistant, watertight construction
- Standards Compliance: Meets CSA C22.2 No.0.17 & No.182.1, IEC standards, UL1682 certification
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.60
- Package Width: 4.60
- Package Height: 6.10
- Package Weight: 2.60
