Watertight Pin & Sleeve Connector, 100 A, 600V AC, Three Phase, 3 Pole, IEC Grounding, Black MPN:HBL4100C5W

• The HUBBELL IEC Pin and Sleeve Connector is an electrical connector rated for use in industrial environments with specified current and voltage ratings. Rated for 100A and 600V AC, this three-phase, four-wire device features a body constructed from impact-resistant materials

• rated for moisture ingress protection as per enclosure standards. The connector uses screw terminals for wire connection and includes a spring-loaded cap designed to support ingress protection as specified by the product’s rating.




  Key Features of the HUBBELL IEC Pin and Sleeve Connector:





  • Current/Voltage Rating: 100A, 600V AC
  • three-phase operation


  • Body Material: Zytel 801 nylon with PBT housing
  • impact resistant


  • Operating Temperature Range: -40°C to 75°C


  • Cable Compatibility: Accepts wire sizes from 3 AWG up to 1/0 AWG
  • cable diameter range from 1.065 in to 1.94 in


  • NEMA Enclosure Rating: Type 4X
  • IP68/IP69K rated for water and dust ingress protection


  • Grounding Style: IEC grounded design with shrouded contacts


  • Features: Color-coded housings for identification, self-closing gasketed cover, insulated non-metallic housing


  • Screw terminal wire connection
  • straight orientation


  • Standards Compliance: CSA Certified LR280C, UL Classified to IEC 60309-1 & -2 (UL E146033)
