WT Mch Intrlk Dvc, 3P4W, 30 A, 480V AC, 15hp MPN:HBL430MI7W
Free Shipping
In Stock
The HUBBELL Watertight Mechanical Interlock is a versatile and reliable solution for indoor and outdoor applications requiring a combined disconnect switch and receptacle. Rated for 30A, 480V AC, three-phase power, it features a non-metallic thermoplastic housing and is compatible with OSHA Lockout/Tagout procedures. Its interlock mechanism restricts plug removal when the switch is engaged, ensuring visual confirmation of disconnection. Suitable for use in harsh environments, this device is ideal for applications in industrial settings, construction sites, and areas with high humidity or exposure to water. Its compact design and durable construction make it a reliable choice for demanding environments.
Top product features:
- Restricts plug removal when the switch is engaged for visual confirmation of disconnection and compatibility with OSHA Lockout/Tagout procedures.
- Features a non-metallic thermoplastic housing rated for indoor and outdoor use.
- Includes a locking handle for secure operation.
Top product applications:
- Industrial electrical control panels
- Construction sites for use in wet or harsh environments
- Marine vessels and offshore oil platforms
The HUBBELL Watertight Mechanical Interlock is an unfused, pin and sleeve device that functions as a combined disconnect switch and receptacle. It is rated for 30 A, 480V AC, three-phase power with four wires and features a non-metallic thermoplastic housing
- rated for indoor and outdoor use. The interlock mechanism includes an interlock mechanism that restricts plug removal when the switch is engaged, allowing for visual confirmation of disconnection and compatibility with OSHA Lockout/Tagout procedures.
Key Features of the HUBBELL Watertight Mechanical Interlock:
- Current Rating: 30 A
- Voltage Rating: 480V AC
- Horsepower Rated: 15 hp
- Electrical Connection Type: Pin and Sleeve (compatible with plug number 5Z941)
- Wire Size Compatibility: Compatible with cord sizes from 12 to 8 AWG
- Enclosure Ratings: IP67 watertight
- NEMA ratings of 4X and 12
- Operating Temperature Range: -40°C to +75°C
- Housing Material: Thermoplastic housing
- UV stabilized components
- Screw Material: Stainless steel (300 series) for corrosion resistance
- Includes locking handle
- No circuit breaker or fuse protection (non-fused design)
- Flammability Ratings: UL94 V-0, UL94 5VA certified materials
- Standards Compliance: UL Listed
- IEC60309-1 & IEC60309-2 compatible design
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.50
- Package Width: 7.50
- Package Height: 7.00
- Package Weight: 6.00
