Flanged Locking Receptacle, L5-15R, 15 A, 125V AC, Single Phase, 2 Pole, Flush Mount, White MPN:HBL4715C

• The HUBBELL 15A Flanged Twist-Lock Receptacle is a flanged locking receptacle intended for use in industrial settings requiring locking electrical connections. This device features a twist-lock mechanism, rated for 15 amps and 125V AC, with a NEMA L5-15R configuration. Constructed from impact-resistant thermoplastic and nylon materials, it is suitable for indoor dry locations where reliable power connectivity is required.





  Key Features of the HUBBELL 15A Flanged Twist-Lock Receptacle:





  • Amperage/Voltage: Rated for 15 A at 125V AC single phase


  • NEMA Configuration: L5-15R (2-pole, 3-wire)


  • Material Construction: Thermoplastic housing with nylon flange (impact resistance per manufacturer specifications)


  • Mounting Type: Flush mount design
  • includes mounting screws and hardware


  • Wire Termination: Backwired screw terminals accept #18 to #10 AWG copper wire
  • accepts slotted, Phillips, and Robertson drivers


  • Operating Temperature Range: -40°C to +75°C (without impact)


  • Dielectric Strength & Performance: Rated dielectric strength: minimum 2,000V
  • listed as current interrupting at full rated current per certification standards


  • Flammability Rating: HB or better per UL94/CSA standards


  • Covers & Protection: Includes cover
  • IP20 rating for indoor use only


  • Certifications & Standards: CSA C22.2 No.42, Federal Specification W-C-596, UL 498 listed
