Locking Plug, Non-NEMA, 30 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Black, White MPN:HBL3331GC

• The HUBBELL 30A Locking Plug is an industrial electrical connector rated for use in specified applications and environments. This locking plug features a ribbed nylon housing

• see specifications for material properties, as well as a cord grip design intended to reduce strain on wire terminations. The clear, funnel-shaped wire entry facilitates wiring process, while an integral dust shield over the wiring chamber helps keep contaminants out.




  Key Features of the HUBBELL 30A Locking Plug:





  • Amperage/Voltage Rating: Rated for 30 A and 250V AC single-phase applications


  • Poles/Wires: 2-pole, 3-wire configuration with screw terminal connections


  • Cable Range: Accepts cable diameters from 0.360" to 0.930"
  • accommodates #16 AWG to #8 AWG stranded copper wire


  • Housing Material: Nylon construction provides chemical and impact resistance
  • ribbed exterior enhances grip


  • Cord Grip Design: Protects against excess strain on terminations during use


  • Wire Entry & Dust Shield: Funnel-shaped entry aids termination
  • integrated dust shield over the wiring chamber helps keep contaminants out


  • Operating Temperature Range: Suitable for continuous operation from -40°C (without impact) up to +75°C


  • Flammability & Dielectric Strength: Meets HB or better per UL94
  • withstands dielectric voltages up to 2,000V minimum


  • NEMA Configuration/IP Rating: Non-NEMA plug type with IP20 suitability (indoor dry locations unless otherwise protected)


  • Standards Compliance: Certified to CSA C22.2 No.42, Federal Specification W-C-596, and listed to UL498 standards
