Duplex Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded MPN:DRUB20
Free Shipping
In Stock
The HUBBELL 20A Duplex DIN Rail Receptacle is a reliable and versatile solution for providing utility power within industrial control cabinets. Designed for use in harsh environments, this duplex receptacle mounts directly onto a standard 35mm DIN rail and features side-wired terminals for easy connection of line, neutral, and ground wires. With its grounded and polarized design, it ensures safe and efficient power delivery. Ideal for industrial applications requiring panel-mounted power access, this receptacle is perfect for use in control panels, enclosures, and other regulated applications, providing a reliable and durable solution for your power needs.
Top product features:
- Rated for 20 amps at 125V AC single phase operation.
- Accepts NEMA 5-20R plugs and has a grounded and polarized design.
- Includes side-wired terminals for connection of line, neutral, and ground wires.
Top product applications:
- Industrial Control Cabinets
- Panel-Mounted Power Access in Industrial Environments
- Utility Power within Enclosures
The HUBBELL 20A Duplex DIN Rail Receptacle (5-20R, 125VAC) is a unit intended for providing utility power within industrial control cabinets. This duplex receptacle mounts directly onto a standard 35mm DIN rail and includes side-wired terminals for connection of line, neutral, and ground wires. The device is intended for use in industrial environments requiring panel-mounted power access.
Key Features of the HUBBELL 20A Duplex DIN Rail Receptacle:
- Amperage/Voltage Rating: Rated for 20 amps at 125V AC single phase operation.
- NEMA Configuration: Accepts NEMA 5-20R plugs
- grounded and polarized design.
- Mounting: Panel mount with vertical orientation on standard DIN rails
- includes mounting hardware.
- Construction: Molded plastic housing with flanged square shape
- constructed from nylon enhances durability in industrial settings.
- Receptacle Type: Standard duplex outlet provides two straight blade connections per gang.
- Cable Entry & Wiring Method: Side-wired terminal block allows installation inside control panels or enclosures.
- Certifications & Standards: UL Listed and CSA Certified for use in regulated applications.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.30
- Package Width: 5.40
- Package Height: 4.10
- Package Weight: 0.80
