Pin & Sleeve Plug, 200 A, 600V AC, Single Phase, 3 Pole, Style 2 Grounding, Black, Gray MPN:HBL4200PS2WR

• The HUBBELL 3P4W 200A 600V Pin & Sleeve Plug, Style 2 Reverse, is a heavy-duty electrical connector intended for use in applications with high current and where a watertight connector is needed. This plug features a composite construction with metallic shrouding and a non-metallic housing, offering both durability and moisture resistance. It is rated for up to 200 amps at 600 volts AC, supports single-phase power with three poles and four wires, and utilizes pressure terminal screws for secure wire connections.





  Key Features of the HUBBELL - 3P4W 200A 600V P/S Plug Style 2 Reverse:





  • Current/Voltage Rating: Rated for up to 200 A at 600 V AC


  • Construction: Composite material with metallic shroud and non-metallic housing


  • Cord Compatibility: Compatible with cable diameters from 1 in to 2.5 in


  • Wire Size Range: Accepts #1 AWG to #250MCM (maximum wire size of 250 kcmil)


  • Environmental Resistance: Rated UL Type 4X for dust-tight sealing via locking ring
  • rated impact resistant


  • Operating Temperature Range: -40°C minimum (without impact), maximum continuous temperature of +75°C


  • Sleeve Contacts: All-brass sleeve contacts


  • Grounding Style: Grounded, Style 2 configuration
  • reversed service hub style


  • Circuit Configuration: Three poles, four wires
  • straight connection orientation


  • Certifications/Standards: CSA Certified (C22.2 No.159), UL Listed (UL1682, UL1010), meets UL Standard requirements including flammability rating UL94 V-0
