Pin & Sleeve Plug, 200 A, 600V AC, Single Phase, 3 Pole, Style 2 Grounding, Black, Gray MPN:HBL4200PS2W

• The HUBBELL Pin & Sleeve Plug is a watertight electrical connector intended for use in industrial settings where robust power connections are needed. It features a composite construction with metallic shrouding and a non-metallic housing, constructed to enhance durability and incorporate features that address electrical safety. This plug accommodates wire sizes from 1 AWG to 250 kcmil and supports up to 200 A at 600V AC single-phase operation.





  Key Features of the HUBBELL Pin & Sleeve Plug:





  • Current/Voltage Rating: Rated for 200 A and up to 600V AC single phase


  • Construction: Composite material with metallic shroud and non-metallic housing


  • Cord Compatibility: Compatible with a range of portable cord types


  • Wire Connection Type: Pressure terminal screws support #1 AWG to #250MCM wire sizes


  • Environmental Resistance: Rated as watertight, moisture-resistant, and impact-resistant
  • UL Type 4X dust-tight seal via locking ring


  • Temperature Range: Operates between -40°C (min) and +75°C (max)


  • Sleeve Contacts: Features all-brass sleeve contacts


  • Certifications/Standards: CSA C22.2 No.159, UL Listed, UL Standard 1682/50/1010
  • meets flammability rating UL94 V-0


  • Pole/Wire Configuration: Single phase, three poles, four wires
  • grounded (Style 2 grounding)


  • Identification: Catalog number and ratings are visible during use
  • terminals identified per UL standards
