Pin & Sleeve Receptacle, 100 A, 125/250V AC, Single Phase, 3 Pole, IEC Grounding, Yellow, NEMA 4X MPN:M4100R12
Free Shipping
In Stock
The HUBBELL Pin and Sleeve Receptacle is a rugged and reliable electrical connector designed for demanding industrial applications. Suitable for use in harsh environments, this 100A, 125/250V AC receptacle features a watertight, corrosion-resistant construction with a yellow thermoplastic housing and nickel-plated solid brass pins. Its spring-loaded cap and external cord clamps ensure added protection against moisture and impact. Ideal for use in manufacturing, construction, and oil and gas industries, this receptacle meets CSA and IEC standards, ensuring safe and reliable connections in the most demanding conditions. Its IP67 rating and NEMA Type 4X enclosure rating make it perfect for use in wet and dusty environments.
Top product features:
- The receptacle is grounded.
- The receptacle has a self-closing gasketed cover to maintain watertight integrity when not in use.
- The receptacle accepts wire sizes from 3 AWG to 1/0 AWG.
Top product applications:
- Industrial control panels
- Heavy-duty machinery installations
- Outdoor construction sites
The HUBBELL Pin and Sleeve Receptacle is a 100A, 125/250V AC electrical connector suitable for industrial applications. It features a watertight, corrosion-resistant construction with a yellow thermoplastic housing and nickel-plated solid brass pins to support reliable connections in demanding conditions. The receptacle is grounded, shrouded, and equipped with a spring-loaded cap for added protection against moisture and impact.
Key Features of the HUBBELL Pin & Sleeve Receptacle:
- Current Rating: Rated for 100 amps at 125/250V AC single-phase operation
- Construction: Nylon body with thermoplastic housing
- corrosion, impact, moisture, and weather resistant
- Cord Retention: External cord clamps are included
- Pins: Nickel-plated solid brass pins
- Connection Orientation: Straight connection using screw terminals
- accepts wire sizes from 3 AWG to 1/0 AWG
- Ingress Protection: IP67 rated for water and dust resistance
- NEMA Type 4X enclosure rating
- Cover Design: Self-closing gasketed cover (spring-loaded cap) helps maintain watertight integrity when not in use
- Identification: Color-coded yellow housing aids quick identification on site
- Standards Compliance: Meets CSA C22.2 No. 0.17 & No.182.1, IEC standards, UL1682 & UL94 HB flammability requirements
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.40
- Package Width: 6.40
- Package Height: 5.90
- Package Weight: 4.10
