GFCI Receptacle, Duplex, 1 Phase, NEMA 5-20R, 125V AC, 20 A, 2 Poles, Screw Terminals, White MPN:GFR20W
Free Shipping
In Stock
The HUBBELL GFCI Receptacle is a reliable and efficient solution for industrial and commercial environments. Suitable for use in a variety of settings, including offices, restaurants, and manufacturing facilities, this duplex outlet offers advanced features such as AUTOGUARD self-test technology, which monitors ground fault protection capability at regular intervals. Visual indicators display power status, trip condition, ground fault detection, and end-of-life notifications, ensuring seamless operation. With its 20A, 125VAC rating and NEMA 5-20R configuration, this receptacle provides reliable and safe power distribution, making it an ideal choice for applications where electrical safety is paramount.
Top product features:
- Self-Testing: Tests GFCI function at regular intervals (every 30 seconds) to ensure continuous protection.
- Visual Indicators: Displays power status, trip condition, ground fault detection, and end-of-life notifications to inform users of the receptacle's status.
- Protection Response: Disconnects power when unable to provide GFCI protection or upon detection of incorrect line/load wiring to prevent electrical shock.
Top product applications:
- Industrial settings
- Commercial environments
- General use in commercial and industrial settings
The HUBBELL GFCI Receptacle is a 20A, 125VAC duplex outlet suitable for use in industrial and commercial environments. It features AUTOGUARD® self-test technology
- rated to monitor ground fault protection capability at regular intervals (every 30 seconds). The device is rated to disconnect power when it detects loss of GFCI protection or damage to certain internal components. Visual indicators on the face display power status, trip condition, ground fault detection, and end-of-life notifications. The receptacle does not supply power when reverse wiring is detected.
Key Features of the HUBBELL GFCI Receptacle:
- Amperage/Voltage: Rated for 20A at 125V AC
- NEMA Configuration: 5-20R decorator duplex outlet
- Self-Testing: Rated to test GFCI function at regular intervals (every 30 seconds)
- Indicators: Visual signals for power status, trip condition, ground fault detection, and end-of-life
- Protection Response: Rated to disconnect power when unable to provide GFCI protection or upon detection of incorrect line/load wiring
- Mounting Type: Flush mount with included mounting hardware
- single gang configuration
- Wiring Method: Accepts both back and side screw terminal connections
- polarized design with grounding feature
- Contact Material/Housing: Brass contacts with nylon housing suitable for general use in industrial/commercial settings
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 5.00
- Package Height: 8.00
- Package Weight: 0.40
