Watertight Locking Plug, L6-15P, 15 A, 250V AC, Single Phase, 2 Pole, Screw Terminals, Yellow MPN:HBL24W49
Free Shipping
In Stock
The HUBBELL 15A Watertight Locking Plug (L6-15P) is designed for use in harsh environments where moisture, dust, and weather resistance are crucial. Its smooth body design minimizes collection points, ensuring reliable performance. Rated for 15 A at 250V AC single phase, this plug is ideal for applications such as outdoor lighting, industrial equipment, and construction sites. Its IP69K rating and UV-stabilized materials ensure long-lasting durability, while its NEMA configuration and UL498 compliance guarantee safety and reliability. Perfect for use in extreme temperatures (-40°C to +60°C), this plug is a reliable choice for a variety of industries and applications.
Top product features:
- Smooth body design minimizes collection points for moisture and dust.
- Rated for 15 A at 250V AC single phase.
- Dielectric strength of up to 2500V AC.
Top product applications:
- Outdoor Lighting Fixtures
- Marine Electrical Applications
- Industrial Control Panels
The HUBBELL 15A Watertight Locking Plug (L6-15P) is an electrical plug rated IP69K for moisture, dust, and weather resistance. It features a smooth body design that minimizes collection points.
Key Features of the HUBBELL 15A Watertight Locking Plug:
- Amperage/Voltage Rating: Rated for 15 A at 250V AC single phase
- NEMA Configuration: L6-15P, locking type with polarized design
- Material Construction: Body and housing made from thermoplastic elastomer
- blade and contact material are nickel-plated brass
- Cord Accommodation: Accepts cable diameters from 0.375 in to 0.625 in
- compatible with wire sizes ranging from 16/3 SJ to 10/3 SJ, or 18/3 S to 12/3 S
- Ingress Protection: IP69K rated for moisture, dust, and weather resistance
- UV stabilized exposed materials
- Operating Temperature Range: -40°C to +60°C continuous operation
- Standards Compliance: Meets ANSI standards as well as NEMA WD-1 and WD-6 requirements
- Performance Ratings: Dielectric strength of up to 2500V AC
- current interrupting per UL498
- temperature rise limited to max of 30°C at rated current
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.00
- Package Width: 6.00
- Package Height: 2.30
- Package Weight: 0.25
