Pin & Slve Plug, 60A, 4P, 3W, 600VAC/250VDC MPN:VP6485
Free Shipping
In Stock
The HUBBELL Pin & Sleeve Plug is a rugged and reliable electrical connector designed for industrial and commercial applications. Suitable for use in harsh environments, including wet, cold, hazardous, corrosive, and marine locations, this plug supports up to 60 amps at 600V AC or 250V DC. Its durable copper-free aluminum housing and baked powder epoxy/polyester finish ensure long-lasting performance. Ideal for use in Class I Divisions 1 & 2 Groups A-D applications, this plug is perfect for a wide range of industries, including manufacturing, construction, and oil and gas. Its versatility and reliability make it an essential component for any electrical system.
Top product features:
- Supports up to 60 amps at 600V AC or 250V DC
- Features a straight connection orientation with screw terminals
- Has an octagonal body style that facilitates handling during connection or disconnection
Top product applications:
- Industrial control panels
- Commercial electrical installations
- Marine and offshore applications
The HUBBELL Pin & Sleeve Plug, 60A, 4P, 3W is an electrical connector intended for industrial and commercial applications. This plug supports up to 60 amps at 600V AC or 250V DC and features a straight connection orientation with screw terminals. Its octagonal body style facilitates handling during connection or disconnection, while the copper-free aluminum housing with baked powder epoxy/polyester finish offers durability in harsh conditions.
Key Features of the HUBBELL Pin & Sleeve Plug:
- Amperage/Voltage Rating: Rated for 60 A, compatible with up to 600V AC or 250V DC circuits
- Poles/Wires: Three poles and three wires configuration
- NEMA Enclosure Rating: Type 4X when mated with VersaMate receptacle and locking ring tightened
- suitable for indoor/outdoor use including wet, cold, hazardous, corrosive, and marine locations
- Hazardous Location Specification: Classified for Class I Divisions 1 & 2 Groups A-D applications
- Material/Finish: Copper-free aluminum housing with electrostatically applied epoxy powder finish improves resistance to corrosion
- Wire Size Compatibility: Accepts wire sizes from #6 AWG to #2 AWG via box terminals with screw terminals/funneled entry chambers guide stripped wires into position during installation
- Cable Entry/Grommet Range: Accommodates cable diameters from 0.65" to 1.50"
- Insulator Strength: Insulators constructed for mechanical and dielectric strength under specified loads improve reliability under load
- Screw Terminals/Funneled Entry Chambers: Guide stripped wires into position during installation by guiding them into place effectively
- Grounding Style/Phase: Grounded (Style II), three-phase compatible design
- Casing Dimensions: Measures approximately 8.81" length x 3.68" width x face diameter of 2.25"
- Standards Compliance: CSA Certified LR111846 and UL E10757 listed product
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.40
- Package Width: 7.40
- Package Height: 5.40
- Package Weight: 3.35
