Snap Action Switch - V15W Series, SPDT, Lever Roller, 5A 240V, IP67 MPN:V15W-DZ200A04-W2
The Honeywell MICRO SWITCH V15W Series Miniature Snap Action Switch is a reliable and durable solution for a wide range of industrial applications. Ideal for use in harsh environments, this switch features a simulated roller lever actuator and is rated for operation within specified voltage and current ranges. With its IP67-rated sealed housing and 3/16 in quick connect terminals, this switch provides convenient electrical connectivity and protection from the elements. Suitable for use in control panels, machinery, and equipment, this switch offers a high level of reliability and performance, making it an excellent choice for demanding industrial applications.
Top product features:
- Actuator: Lever type with simulated roller
- Contact form: SPDT (1NO/1NC)
- IP67-rated sealed housing provides ingress protection
Top product applications:
- Industrial Control Panels
- Automotive Systems
- Machine Tools
Honeywell MICRO SWITCH V15W Series Miniature Snap Action Switch features a simulated roller lever actuator and is rated for operation within specified voltage and current ranges (up to 10 A). This switch is constructed with materials and features suitable for industrial environments, with an IP67-rated sealed housing that provides ingress protection as defined by the standard. Electrical connectivity is provided via 3/16 in quick connect terminals, and the unit carries certifications from CQC, ENEC, UL, and cUL.
Key features:
- - Actuator: Lever type with simulated roller
- length 1.28"
- - Contact form: SPDT (1NO/1NC)
- - AC contact rating: 5 A @ 240 V
- - DC contact rating: 5 A @ 30 V
- - Body material: PBT polyester thermoplastic
- - Operating temperature range: -40°F to 185°F
- - Mounting dimension: 0.87 in centers
- mounting hole diameter: 7/8 in
- - Differential travel maximum: 0.04 in
- max pretravel: 0.13 in
- overtravel: up to 0.07 in
- - Overall dimensions (WxHxD): 1.3 x 0.63 x 0.41 in
- - Terminal type: Quick connect
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.10
- Package Width: 1.00
- Package Height: 0.40
- Package Weight: 0.01
