Limit Switch - Plunger, Boot Seal, DPDT, Zinc Die Cast, IP66 Rated MPN:DTE6-2RN
The Honeywell MICRO SWITCH DTE6 Series limit switch is a compact, miniature-style switch ideal for a variety of applications, including industrial automation, HVAC, and medical equipment. Its plunger actuator with boot seal ensures reliable operation in both indoor and outdoor environments, while its zinc die-cast housing provides durability and resistance to corrosion. With a DPDT contact form and 10A at 240V AC/DC rating, this switch is suitable for a range of applications, including conveyor systems, robotics, and machinery control. Its IP66 rated enclosure and CSA and UL certification make it a reliable choice for demanding environments.
Top product features:
- Contact Form: 2NC/2NO (DPDT)
- AC/DC Contact Rating: 10A at 240V
- IP66 rated enclosure
Top product applications:
- Machine control systems
- Automotive applications
- Industrial automation
Honeywell MICRO SWITCH DTE6 Series limit switch features a plunger actuator with boot seal, suitable for use in indoor and outdoor environments, as specified by the manufacturer. The zinc die-cast housing is coated with electrostatic epoxy coating applied to the housing. This compact, miniature-style switch features a top-mounted actuator and bottom flange mounting configuration
- compact dimensions are provided above.
Key Features:
- - Contact Form: 2NC/2NO (DPDT)
- - AC/DC Contact Rating: 10A at 240V
- - Actuator Style: Plunger, boot sealed
- Actuator Length: 1.06 in
- - Body Material: Zinc die cast
- Body Dimensions (H x W x D): 2.3 x 1.0 x 3.04 in
- - Mounting Style: Bottom flange
- Number of Mounting Holes: 2 (0.17 in diameter), Horizontal spacing: 1.63 in
- - Electrical Connection: Screw terminals
- Wiring Entry: 1/2 in NPT
- - Operating Force Range: 26 ozf to 59 ozf
- - Travel Parameters: Differential travel—0.06 in, Pretravel—0.11 in, Overtravel—0.13 in minimum
- - IP66 rated enclosure
- Standards met include CSA and UL
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 2.40
- Package Height: 4.40
- Package Weight: 0.65
