Limit Switch - Compact, SPDT, Roller Lever, 15A 600V AC, Surface Mount MPN:BZE6-2RQ2
Limit Switch - Compact, SPDT, Roller Lever, 15A 600V AC, Surface Mount
The Honeywell Limit Switch, part of the BZ Series, is a general purpose miniature limit switch suitable for surface mounting applications. It features a plunger with a horizontal steel roller lever actuator and offers single-pole double-throw (SPDT) contacts with 1 normally closed (NC) and 1 normally open (NO) contact. The zinc die cast body has a compact design
- refer to dimensions for installation requirements.
Key Features:
- - Contact Ratings: 15A at 600V AC
- 2A at 250V DC
- - Actuator Style: Plunger with horizontal steel roller lever
- actuator length of 0.91"
- - Body Dimensions: Height 1.75", width 3.04", depth/overall depth 1"
- - Mounting: Surface mount with two horizontally spaced holes (1" apart), hole diameter of 0.22"
- - Electrical Connection: Screw terminals
- wiring entry via 1/2" NPT
- - Mechanical Travel: Pretravel of 0.19", overtravel of 0.22", differential travel of 0.01"
- - Operating Force: Minimum force required is 10 ozf, maximum is 18 ozf
- - Temperature Range: Rated for operation within -25°F to +160°F temperature range
- - Protection Ratings: IP66 ingress protection
- NEMA Type 1 enclosure rating
- - Standards Compliance: CSA and UL listed
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.10
- Package Width: 2.50
- Package Height: 4.10
- Package Weight: 0.75
Product info last updated on February 3, 2026 12:28am UTC
