Limit Switch - Heavy Duty, DPDT, Side Plunger Roller, 10A 600V, NEMA Rated MPN:LSF4L
The Honeywell Heavy Duty Limit Switch is a reliable and versatile device designed for use in various limit switch applications. Its heavy-duty construction and corrosion-resistant materials ensure long-lasting performance in harsh environments. With a side-mounted plunger actuator and DPDT contacts, this switch offers flexible configuration options and high current capacity. Suitable for use in industrial settings, the switch is rated for up to 600V AC or 250V DC operation and features a NEMA-rated enclosure for added protection. Ideal for applications such as machinery control, conveyor systems, and material handling equipment, this limit switch provides dependable operation and easy installation.
Top product features:
- The Honeywell Heavy Duty Limit Switch features a side-mounted plunger actuator with a roller.
- It offers double pole, double throw (DPDT) contacts with 2 normally open (NO) and 2 normally closed (NC) configurations.
- It has a die cast zinc body made from materials specified as corrosion resistant by the manufacturer.
Top product applications:
- Limit Switch Heavy Duty, DPDT, Side Plunger Roller, 10A 600V, NEMA Rated from Honeywell is suitable for use in industrial automation, particularly in applications that require a high level of reliability and durability.
- This product is ideal for use in conveyor systems, where the side-mounted plunger actuator with a roller can be used to detect the presence or absence of a product.
- The Heavy Duty Limit Switch is also suitable for use in machinery and equipment, such as presses and pumps, where the double pole, double throw (DPDT) contacts and corrosion-resistant body can provide reliable and consistent operation.
The Honeywell Heavy Duty Limit Switch is a non plug-in, momentary-action device intended for use in limit switch applications. It features a side-mounted plunger actuator with a roller and utilizes a die cast zinc body made from materials specified as corrosion resistant by the manufacturer. The switch offers double pole, double throw (DPDT) contacts with 2 normally open (NO) and 2 normally closed (NC) configurations, rated at 10A for up to 600V AC or 250V DC operation. The unit is equipped with screw terminals for electrical connection and has surface mounting capability.
Key Features:
- - Contact Rating: 10A at 600V AC / 10A at 250V DC
- - Contact Form: DPDT (2NO/2NC)
- - Actuator Style: Side-mounted plunger with steel roller
- actuator length of 1.74"
- - Body Construction: Die cast zinc housing
- made from materials specified as corrosion resistant by the manufacturer
- - Enclosure Ratings: NEMA types 1, 3, 4, 4X, 6, 6P,12,13
- IP65/66/67
- - Mounting Style: Surface mount with two diagonal holes (0.20" diameter), spacing of 2.34" x 1.16"
- - Operating Temperature Range: -12°C to +93°C (10°F to +200°F)
- - Electrical Connection: Screw terminals via threaded entry (3/4" NPT)
- - Mechanical Travel Specs: Pretravel—0.1", Overtravel—0.19", Differential travel—0.04"
- - Roller Dimensions: Diameter—0.5", Width—0.19"
- made of steel
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 70 days
- Minimum Order Quantity: 5
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 3.20
- Package Height: 2.20
- Package Weight: 5.11
