Limit Switch - Heavy Duty, Plunger Actuator, DPDT, 10A, NEMA/IP67 Rated MPN:LSV7L
The Honeywell Heavy Duty Limit Switch is a rugged and reliable plunger-style device designed for heavy-duty industrial and commercial applications. Suitable for use in a variety of settings, including manufacturing, material handling, and automation, this switch offers momentary action and supports both AC and DC ratings. Its adjustable linear plunger actuator provides precise control and flexibility, while its NEMA/IP67 rated housing ensures protection against dust, water, and other environmental factors. Ideal for applications where reliability and durability are essential, the Honeywell Heavy Duty Limit Switch is a trusted choice for industries seeking high-performance switching solutions.
Top product features:
- Contact Form: Double pole double throw (2NC/2NO)
- Actuator Style: Plunger
- Adjustable movement
Top product applications:
- Industrial Automation
- Machine Guarding
- Conveyor Systems
The Honeywell Heavy Duty Limit Switch is a plunger-style device suitable for industrial and commercial applications. Part of the HDLS Series, it features a zinc die cast miniature body with a top-mounted, adjustable linear plunger actuator. The switch offers momentary action and supports both AC (10A at 600V) and DC (10A at 250V) ratings, utilizing screw terminals for electrical connections. Its housing constructed to meet specified NEMA enclosure standards (1, 3, 4, 4X, 6, 6P, 12, 13) and IP65/66/67 ingress protection ratings.
Key Features:
- - Contact Form: Double pole double throw (2NC/2NO)
- - Actuator Style: Plunger
- Length: 2.34 in
- Adjustable movement
- - Body Dimensions: Height – 2.95 in
- Width – 1.88 in
- Depth – 1.79 in
- - Mounting: Surface mount with two diagonal holes (0.20 in diameter), spacing of 2.34 x 1.16 in
- - Electrical Ratings: Up to 10A at either 600VAC or 250VDC
- - Operating Temperature Range: From +10°F to +200°F
- - Mechanical Travel Specs: Pretravel – max 0.07 in
- Differential travel – max 0.02 in
- Overtravel – min 0.19 in
- - Ingress Protection & Enclosure Ratings: NEMA types listed above and IP65/IP66/IP67
- - Certifications: CCC, CE, CSA, UL
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.10
- Package Width: 2.20
- Package Height: 5.90
- Package Weight: 2.00
