Miniature Limit Switch - 914CE, SPDT, Side Rotary Head, 6 ft Cable, NEMA Rated MPN:914CE16-6
The Honeywell 914CE Series Limit Switch is a compact, enclosed rotary switch designed for a variety of applications in North America. Its side-mounted rotary actuator head and spring return action make it suitable for use in a range of industries, including manufacturing, automation, and control systems. The switch features SPDT contacts rated at 5A, 240V AC and meets NEMA enclosure ratings and ingress protection standards. Its compact size and pre-wired 6 ft cable make it easy to integrate into existing systems, while its CE marked and CSA certified design ensures compliance with international safety standards.
Top product features:
- Compact, enclosed rotary switch suitable for a variety of applications.
- Side-mounted rotary actuator head without a lever provides a convenient and space-efficient design.
- Pre-wired 6 ft cable facilitates easy electrical connection.
Top product applications:
- Machine Guarding
- Conveyor Systems
- Automated Material Handling
For use in North America, the Honeywell 914CE Series Limit Switch is a compact, enclosed rotary switch suitable for a variety of applications. This model features a side-mounted rotary actuator head without a lever and includes SPDT (1NC/1NO) contacts rated at 5A, 240V AC. The switch body is constructed from die-cast zinc with a miniature form factor and includes a pre-wired 6 ft cable for electrical connection. It is constructed to comply with specified NEMA enclosure ratings and ingress protection standards.
Key Features:
- - Contact Rating: 5A at 240V AC (SPDT: 1NC/1NO)
- - Actuator Style: Side rotary head without lever
- spring return action
- - Body Construction: Miniature die-cast zinc housing
- - Electrical Connection: Pre-wired with a 6 ft SJTO cable
- - Mounting: Surface mount with two horizontal holes (0.2 in diameter
- spaced at 0.98 in center-to-center)
- - Movement & Travel: Operates CW or CCW
- differential travel of 3°, pretravel of 30°, overtravel of 40°
- - Environmental Ratings: NEMA types 1,2,3,3R,4,6,6P &13
- IP66/IP67/IP68
- - Operating Temperature Range: From 35°F to160°F (2°C to71°C)
- - Standards Met: CE marked
- CSA certified
- IEC947-5-1
- EN60947-5-1
- UL listed
Additional Information
- Country of Origin: GB
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 7.50
- Package Height: 1.00
- Package Weight: 0.90
