Miniature Limit Switch - SPDT, Plunger, Boot Sealed, 9 ft Cable, Zinc Body MPN:914CE18-9A
The Honeywell 914CE Series Limit Switch is a compact, versatile solution for a wide range of applications. Suitable for surface mounting, this miniature switch features a top-mounted plunger actuator with boot sealing, providing reliable operation in harsh environments. With a 9 ft side-exit cable and zinc die-cast body, it's perfect for use in industrial settings, such as manufacturing, material handling, and automation. Its robust construction and NEMA-rated enclosure ensure durability and protection from dust and water, making it an ideal choice for applications where reliability and safety are paramount.
Top product features:
- Contact Rating: 5A at 240V AC
- SPDT configuration with one NC and one NO contact
- Boot-sealed plunger actuator
Top product applications:
- Automotive applications such as gear shifting or speedometer calibration
- Industrial automation and control systems including conveyor belt monitoring and machinery control
- Medical equipment and devices requiring precise control and safety features
The Honeywell 914CE Series Limit Switch is a compact, enclosed switch suitable for a variety of applications as specified by the manufacturer. It features a top-mounted plunger actuator which includes boot sealing per product specifications and is configured as SPDT with one NC and one NO contact according to product design. The switch body is constructed from zinc die cast material in a miniature style, offering surface mounting capability via two horizontal holes. Electrical connection is provided by a 9 ft side-exit cable.
Key Features:
- - Contact Rating: 5A at 240V AC
- - Contact Form: SPDT (1NC/1NO)
- - Actuator Style: Plunger, boot sealed
- actuator length 0.62 in
- located on top
- - Body Dimensions: Height 1.73 in, Width 1.58 in, Depth 0.63 in
- - Mounting: Surface mount with two horizontal holes (0.2 in diameter, spaced 0.98 in apart)
- - Enclosure Ratings: NEMA types 1, 2, 3, 3R, 4, 6, 6P, and13
- IP66/IP67/IP68
- - Operating Temperature Range: Minimum of 32°F to maximum of either160°F or221°F as specified
- - Cable Length: Side exit cable measuring9 ft
Additional Information
- Country of Origin: GB
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 100 days
- Minimum Order Quantity: 5
- Unit of Measure: EA
- Package Length: 44.00
- Package Width: 7.00
- Package Height: 1.70
- Package Weight: 4.85
