Limit Switch - Heavy Duty, Rotary Head, 2NC/2NO, Zinc Die Cast, NEMA/IP67 MPN:LSYAB2B
Limit Switch - Heavy Duty, Rotary Head, 2NC/2NO, Zinc Die Cast, NEMA/IP67
The Honeywell Heavy Duty Limit Switch, part of the LSY Series, is a rotary-style limit switch suitable for industrial and commercial applications
- rated per listed specifications. This model features a side-mounted rotary actuator head without a lever and offers momentary action with 2NC/2NO (DPDT) contact configuration. The body is constructed from zinc die cast material, which is resistant to corrosion as specified by manufacturer standards, providing durability in demanding settings. It supports both clockwise (CW) and counterclockwise (CCW) operation, with surface mounting facilitated by two diagonal mounting holes.
Key features:
- - Contact Ratings: 10A at 600V AC
- 10A at 250V DC
- - Actuator Style: Rotary head, no lever
- side location
- - Body Dimensions: Height 4.69 in, Width 1.88 in, Depth 1.79 in
- - Mounting: Surface mount with two diagonal holes (0.20 in diameter), spacing of 2.34 x 1.16 in
- - Electrical Connection: Screw terminals
- wiring entry via 3/4 in NPT
- - Travel Specifications: Differential travel of 7°, pretravel of 15°, overtravel of 60°
- - Operating Force/Torque: Maximum operating force of 4.0 in-lb
- torque up to 4 in-lb
- - Temperature Range: -40°F to +250°F
- - Enclosure Ratings: NEMA types 1, 3, 4, 4X, 6, 6P, 12 & 13
- IP65/66/67 rated for ingress protection
- - Standards Compliance: CCC, CE, CSA, UL
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.10
- Package Width: 3.10
- Package Height: 2.20
- Package Weight: 2.05
Product info last updated on February 24, 2026 8:23am UTC
Category: Industrial Electrical Controls and Automation
