Snap Action Switch - BA Series, SPDT, Roller Plunger, 20A, Screw Terminal MPN:BA-2RB-A2
The Honeywell BA Series Snap Action Switch is a reliable and versatile solution for a wide range of applications. This large snap-action switch features a robust overtravel roller plunger actuator and a single-pole double-throw (SPDT) contact form, making it ideal for use in control panels, machinery, and equipment where high reliability and durability are critical. With a high AC contact rating of 20A at 480V and a range of operating temperatures, this switch can handle demanding applications with ease. Its compact design and screw terminals make it easy to integrate into existing systems, offering a reliable and efficient solution for a variety of industrial and commercial applications.
Top product features:
- Operates within a specified differential travel range to ensure consistent and reliable switching performance.
- Features an overtravel roller plunger actuator that provides a clear and distinct switching action.
- Has a screw terminal electrical connection that allows for easy and secure wiring.
Top product applications:
- Machine control panels
- Industrial control systems
- Automated manufacturing equipment
Rated for operation within specified parameters, the Honeywell Snap Action Switch from the BA Series is configured to operate within the specified differential travel range. This large snap-action switch features an overtravel roller plunger actuator and a single-pole double-throw (SPDT) contact form. It is constructed with a phenolic housing and utilizes screw terminals for electrical connections.
Key Features:
- - AC Contact Rating: 20 A at 480 V
- - DC Contact Rating: 0.5 A @ 125 V, 0.25 A @ 250 V
- - Actuator Type: Overtravel roller plunger
- actuator length of 1.94"
- - Operating Force: Minimum 14 ozf, maximum 22 ozf
- release force of 10 ozf
- - Differential Travel: Minimum 0.002 in, maximum 0.0075 in
- - Pretravel Maximum: 0.05 in
- overtravel of up to 0.094 in
- - Body Dimensions: Width/length of 1.94", height of 0.95", depth of approximately 0.06"
- - Mounting Hole Distance: Center-to-center spacing of 1" with mounting hole diameter at #8 (1/8")
- - Electrical Connection: Bottom-facing screw terminal (6–32 x .218 in.) with cup washer
- - Operating Temperature Range: -67°F to +185°F (-55°C to +85°C)
- - Standards Met: CE, CSA, ENEC, UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.00
- Package Width: 1.60
- Package Height: 0.70
- Package Weight: 0.07
